TP-Link SX3832 24-Port 10GBASE-T L2 Switch

Overview

• 24× 10/100/1000 Mbps RJ45 PoE+ ports, plus 8× 10G SFP+ slots, and 1× RJ45 Console Port plus 1× USB Type-C Console Port
• Rack-mountable, dual-console options, and Omada-ready for centralized management
• Robust security and comprehensive L2/L2+ features for enterprise networks
• Power: 100-240 V AC; PoE+ ports support up to 30 W per port; 500 W PoE budget details appear in device specs
• Cooling: 2 fans; physical security lock; managed via Web GUI and CLI

Key Specifications

• Interfaces: 24 × RJ45 PoE+ ports; 8 × 1/10G SFP+ slots; 1 × RJ45 Console; 1 × USB-C Console
• Power: 100–240 V AC ~50/60 Hz
• PoE: 802.3at/af (PoE+); 48 PoE+ ports (Note: confirm whether model variants exist with 24 PoE+ ports or different PoE distribution)
• PoE Budget: 500 W
• Dimensions (W × D × H): 17.3 × 8.7 × 1.7 in (440 × 220 × 44 mm)
• Weight: [Add weight if known]
• Management: Omada Cloud-Based Controller, Omada Hardware Controller, Omada Software Controller; Web-based GUI; HTTPS; SSH; SNMP v1/v2c/v3
• Certifications: CE, FCC, RoHS
• Note: Power adapter and specific bundle contents should be confirmed per regional model

Hardware Features

• Fans: 2
• Physical Security Lock: Yes
• Mounting: Rack Mountable
• Console: 1× RJ45 Console, 1× USB Type-C Console
• Temperature and environmental specs: See product datasheet

Software Features

• Quality of Service: 8 priority queues; 802.1p/DSCP; SP/WRR; bandwidth control; QoS remark
• L2/L2+: 128 IPv4/IPv6 interfaces; Static Routing (48 IPv4/IPv6); DHCP Server/Relay; L2 Relay; Link Aggregation; Spanning Tree; Loopback Detection; 802.3x Flow Control; Mirroring
• VLAN: 4K VLAN Groups; 802.1Q tagging; MAC VLAN; Protocol VLAN; GVRP; Private VLAN; VLAN VPN mappings
• Multicast & IGMP: IGMP Snooping; MVR; MLD Snooping; Multicast Filtering
• Security: IP-MAC-Port Binding; DHCP Snooping; ARP Inspection; IPv4/IPv6 Source Guard; 802.1X; AAA; Port Isolation; HTTPS/SSL; SSH; RADIUS; Access Control Lists (ACLs)
• IPv6: Dual IPv4/IPv6; MLD, IPv6 ACLs, IPv6 ND
• Management & Automation: Automatic Device Discovery; Batch Config/Upgrade; Unified Configuration; Reboot Schedule; Zero-touch provisioning via Omada
• MIBs: Standard TP-Link private MIBs; RMON

What’s in the Box

• SX3832 Switch
• Power Cord
• Console Cable
• Quick Installation Guide
• Rackmount Kit
• Rubber Feet

Certifications

• CE, FCC, RoHS

Notes

• Some features and exact port counts may vary by hardware revision or region. Verify the exact package contents and power adapter inclusions for your SKU
