The Lenovo ThinkSystem SR550 dual-socket 2U rack server is ideal for small to large organizations that need industry-leading reliability, management, and security, as well as cost-optimized performance, storage capacity, and flexible I/O. Designed to handle a wide range of workloads, the SR550 server costeffectively performs complex analytics on structured and unstructured data, speeds transactional systems, and powers through collaboration workloads with ever-growing data sets and large files shared within an organization.

Featuring the second generation of the Intel Xeon Processor Scalable Family, the SR550 server offers a balance of performance, capacity and value. The SR550 server supports up to two processors, up to 768 GB of 2933 MHz TruDDR4 memory, up to 16x 2.5-inch or up to 12x 3.5-inch drive bays with an extensive choice of SAS/SATA SSDs and SAS/SATA HDDs, and flexible and scalable I/O expansion options with a LOM slot and up to 6x PCIe slots. The built-in next-generation Lenovo XClarity Controller provides advanced service processor control, monitoring, and alerting functions.

  • Gigabit Ethernet port for ultra-fast network speeds
  • RAID provides data reliability, fault tolerance and improves overall performance through RAID levels (0, 1, 5, 6, 10, 50, 60, JBOD)
  • 1 x 750 W power supply unit (PSU) included
  • With 16 GB memory, you can multitask between applications smoothly
  •

Network & Communication
Ethernet Technology Gigabit Ethernet
Warranty
Additional Warranty Information Three-year customer-replaceable unit (CRU) and onsite limited warranty with 9x5 Next Business Day Parts Delivered.
Chipset
Chipset Manufacturer Intel
Chipset Model C622
Display & Graphics
Graphics Controller Model G200
Graphics Memory Capacity 16 MB
Storage
Optical Drive Type No
Total Hard Drive Capacity No
Controllers
RAID Levels 0, 1, 5, 6, 10, 50, 60, JBOD
Controller Type 12Gb/s SAS
  Serial ATA/600
RAID Supported Yes
Controller Model 930-16i
Miscellaneous
Package Contents
  • ThinkSystem SR550 7X04A073AU Server
  • Rack Installation Guide
  • Slide Rail Kit
Security Features
  • Power-on password
  • Administrator's password
  • secure firmware update
  • Trusted Platform Module (TPM) 1.2 or 2.0 (configurable UEFI setting).
Environmentally Friendly Yes
Energy Star Yes
Energy Efficiency Certification ENERGY STAR 3.0
Environmental Compliance Restriction of Hazardous Substances (RoHS)
Physical Characteristics
Weight (Approximate) 26 kg
Form Factor Rack
Rack Height 2U
Height 86.4 mm
Width 444.5 mm
Depth 764.5 mm
I/O Expansions
Number of Total Expansion Bays 12
"Number of 3.5"" Bays" 12
Total Number of Expansion Slots 1
Hot Swappable Bays Yes
PCI Express x8 (Gen 3.x) Slots 1
Number of LFF Bays 12
PCI Express Details 1x PCIe x8
Power Description
Input Voltage 230 V AC
  120 V AC
Plug/Connector Type C13/C14
Number of Power Supplies Supported 2
Number of Power Supplies Installed 1
Hot Swappable Power Supply Yes
Maximum Power Supply Wattage 750 W
Interfaces/Ports
VGA Yes
Number of Network (RJ-45) Ports 2
Network (RJ-45) Yes
Remote Management Yes
Total Number of USB Ports 4
Number of USB 2.0 Ports 1
Number of USB 3.0 Ports 3
Remote Management Controller XClarity Controller Enterprise
Memory
Error Checking ECC
Maximum Memory Supported 768 GB
Signal Processing Registered (Buffered)
Standard Memory 16 GB
Memory Technology TruDDR4
Number of Occupied Memory Slots 1
Memory Clock Speed 2.67 GHz
Total Number of Memory Slots 12
Processor
Cache 11 MB
Processor Speed 2.10 GHz
Processor Type Xeon Silver
Processor Model 4208
Processor Core Octa-core (8 Core)
Number of Processors Supported 2
Number of Processors Installed 1
Processor Generation 2nd Gen
General Information
Product Type Server
Manufacturer Part Number 7X04A073AU
Manufacturer Website Address http://www3.lenovo.com/au/en
Manufacturer Lenovo Group Limited
Product Model 7X04A073AU
Product Name ThinkSystem SR550 7X04A073AU Server
Product Line ThinkSystem
Product Series SR550
Brand Name Lenovo
Operating System
Operating System No
Operating System Supported Red Hat Enterprise Linux 7.7
  Red Hat Enterprise Linux 7.8
  Red Hat Enterprise Linux 7.9
  Red Hat Enterprise Linux 8
  Red Hat Enterprise Linux 8.5
  Red Hat Enterprise Linux 8.6
  Red Hat Enterprise Linux 9.0
  SUSE Linux Enterprise Server 12 SP4
  SUSE Linux Enterprise Server 12 SP5
  SuSE Linux Enterprise Server 15
  SUSE Linux Enterprise Server 15 SP1
  SUSE Linux Enterprise Server 15 SP2
  SUSE Linux Enterprise Server 15 SP3
  Windows Server 2016
  Windows Server 2019
  Windows Server 2022
  Red Hat Enterprise Linux 8.1
  Red Hat Enterprise Linux 8.2
  Red Hat Enterprise Linux 8.3
  Red Hat Enterprise Linux 8.4
  Red Hat Enterprise Linux 7.6
SKU 7X04A073AU
Barcode # 7X04A073AU
Brand Lenovo
Shipping Weight 6.0000kg
